Hardware overview

The AKKR8 Sensor is a remote autonomous sensing system that allows the measuring of sensor data such as industrial sensors, temperature and humidity, air quality and acceleration and it can be expanded to measure other things as well. With a cellular connection built into the unit, the measurements can be uploaded to the internet on a periodic basis.

AKKR8® is a platform that can work with numerous sensors, internal and external. AKKR8® Devices are intended to make testing of IoT easy, fast and inspiring.

The device has a Powerful CPU that runs our operating system that is based on MicroPython. The design has an ultra-low power usage and is very kind on batteries even though it has a microcontroller.

Technical specification

Cellular Module:

Cellular module withCAT-M1 and NB1 support (CAT-M1 support as standard)

Cellular Bands:

Low bands: 5, 8, 12, 13, 14, 17, 18, 19, 20, 26, 28 (699-960 MHz)
Mid bands: 1, 2, 3, 4, 25, 66 (1710 to 2170 MHz)
World wide cellular support (although currently we have only CE and UKCA-tested the device)

Cell support

3GPP release 13 LTE Advanced Pro
Narrowband LTE UE categories M1/NB1

Data rates:

300kbps DL/375 kbps UL (LTE Cat M1)

Processing:

Espressif ESP32 SoC
Main processor for user applications
Coprocessor that controls peripherals during deep-sleep mode

Memory:

RAM: 4MB
Flash Memory: 8MB
-used for datastorage and our operating system

Power consumption deep-sleep:

25uA

Security & Certifications:

SSL/TLS support up to 1.2

CE/UKCA

ce label AKKR8 Sensor conforms with CE and UKCA. The sensor conforms with EN61326-1:2013. The CE-certificate can be downloaded here.

Safety

AKKR8 Sensor conforms with EN 61010:1.

Lithium batteries

lithium label Some of the AKKR8 sensor models contains a Li-Ion battery that is rechargeable and can be replaced by a new battery if needed. The device contains the charger so it is very important not change to another battery. The battery must be sourced from AKKR8 only. Using another battery is dangerous. Models with battery has this label on the outside of the box:

Recycling

recycle Batteries supplied with the sensor should be recycled, contact AKKR8 AB for advise on where and how to dispose your battery.

Radio transmitter

The AKKR8 sensor contains a radio transmitter and is not meant to be within 20cm of a person’s head when in normal use.

The protection features built into this unit may be impaired if not used according to the instructions provided. In applications that do not directly meet the way the AKKR8 Sensor is expected to be used, discuss your application with us for further advice.

AKKR8 AB
